Next-Gen PCU Paint Protection Film
Engineered with polycarbonate TPU for extreme durability, 3× hydrolysis resistance, and long-lasting optical clarity.
Material Specifications – Raw Film Performance
Our PCU PPF uses high-performance polycarbonate TPU substrate with premium adhesive and coating systems. Every batch is tested for stain removal, scratch resistance, and chemical durability to ensure consistent quality for professional installers and distributors worldwide.
PET:
50um±1
Top Coating:
7±1μm
TPU Layer:
150±3um
Adhesive Layer:
27μm±1
Release PET:
75um±1
Peel Strength:
≥1200gf
Gloss Rate:
≥98GU
Brightness Enhancement:
>50%
Elongation:
≥280%
Scratch Repair:
98%
PET:
50um±1
Top Coating:
7±1μm
TPU Layer:
170±3um
Adhesive Layer:
28μm±1
Release PET:
75um±1
Peel Strength:
≥1200gf
Gloss Rate:
≥98GU
Brightness Enhancement:
>50%
Elongation:
≥290%
Scratch Repair:
98%
PET:
50um±1
Top Coating:
7±1μm
TPU Layer:
205um±3
Adhesive Layer:
29μm±1
Release PET:
75um±1
Peel Strength:
≥1200gf
Gloss Rate:
≥98GU
Brightness Enhancement:
>50%
Elongation:
≥300%
Scratch Repair:
98%
PET:
50um±1
Top Coating:
7±1μm
TPU Layer:
235um±3
Adhesive Layer:
30μm±1
Release PET:
75um±1
Peel Strength:
≥1200gf
Gloss Rate:
≥98GU
Brightness Enhancement:
>50%
Elongation:
≥310%
Scratch Repair:
98%
Finished Product Specifications – Technical Data Sheet
Our PCU PPF finished rolls deliver premium protection with ultra-gloss hydrophobic coating, polycarbonate TPU substrate, and proven thermal stability. Each roll is manufactured to exacting standards for consistent performance in every installation.
| Parameter | PCT-75 | PCT-85 | PCT-95 | PCT-120 |
|---|---|---|---|---|
| Thickness: | 7.5mil | 8.5mil | 9.5mil | 11.5mil |
| Width: | 1524mm | 1524mm | 1524mm | 1524mm |
| Length: | 15 meters | 15 meters | 15 meters | 15 meters |
| Net Weight: | 8.7115kg | 9.432kg | 10.398kg | 11.435kg |
| Gross Weight: | 11.2235kg | 11.944kg | 12.91kg | 13.947kg |
| Tensile Strength: | 19.7Mpa | 20.6Mpa | 21.15Mpa | 22.96Mpa |
| Elongation at Break: | 479.20% | 491.14% | 514.60% | 558.85% |
| Gloss Level: | ≥116.3% | ≥124% | ≥129.2% | ≥145.33% |
| Adhesion Force: | 2014gf | 2226.7gf | 2143gf | 2200gf |
| Tear Strength: | ≥114.22KN/m | ≥118.22KN/m | ≥119.22KN/m | ≥125.47KN/m |
| Outer packaging dimensions(mm): | 1575*179*159 (Equiped with 150*150mm end caps) | 1575*179*159 (Equiped with 150*150mm end caps) | 1575*179*159 (Equiped with 150*150mm end caps) | 1575*179*159 (Equiped with 150*150mm end caps) |
| Anti-fouling: | ≥97% | ≥99% | ≥99% | ≥99% |
| Repair Function: | 100% | 100% | 100% | 100% |
| Yellowing: | ≤8% in 5 Years | ≤6% in 5 Years | ≤5% in 5 Years | ≤3% in 5 Years |
| Scratch Proof: | 99% | 99% | 99% | 99% |
| Warranty: | 10 Years | 10 Years | 10 Years | 10 Years |
可删4？
Premium Vehicles Ideal for PCU PPF Protection
Our PCU PPF is trusted by owners of luxury sedans, flagship SUVs, and high-performance sports cars. Below are some of the most popular models our clients frequently protect with our premium polycarbonate TPU film.
✓BMW 7 Series✓Mercedes-Maybach S-Class✓Porsche Panamera✓Lexus RX✓Cadillac LYRIQ✓Volvo XC90✓Aston Martin DBX✓Toyota Alphard✓Porsche 718 Cayman/Boxster✓Range Rover Sport✓Genesis G90✓Maserati Quattroporte✓Bentley Bentayga✓and more ...
可删5？
Key Markets Where PCU PPF Is Most Popular
Our PCU PPF is widely sought after in developed markets with extreme climates, high car ownership, and strong demand for premium paint protection. Below are some of the countries where our PCU films are most frequently purchased.
✓United States✓United Arab Emirates✓Germany✓United Kingdom✓Switzerland✓Morocco✓Saudi Arabia✓Qatar✓China HK SAR✓Singapore✓Australia✓Kuwait✓Bahrain✓and more...
Recommended Other Paint Protection Films
Looking for a reliable PPF supplier?
Tell us your purchase needs and we will recommend you the right PPF solution.
